Specifications
Stator Diameter | 40 mm (1.57 in) |
Stator Thickness | 35 mm (1.024 in) |
No. of Stator Arms | 12 |
Magnet Poles | 10 |
Motor Wind | 9 Turn Delta |
Motor Wire | 21 – Strand 0.29mm |
Motor Kv | 500KV RPM / Volt |
No-Load Current (IO) | 2.02 Amps @ 10v |
Motor Resistance (RM) | 0.016 Ohms |
Max Continuous Current | 84 Amps |
Max Continuous Power | 3500 Watts |
Weight | 460 Grams (16.22 oz) |
Outside Diameter | 49.98 mm (1.97 in) |
Shaft Diameter | 5.98 mm (0.235 in) |
Body Length | 61.8 mm (2.43 in) |
Overall Shaft Length | 100.0 mm (3.93 in) |
Max Lipo Cell | 12s |
Peak Current | 104A (5 seconds) |
Peak Power | 4600 Watts (5 seconds) |
Motor Timing | 5deg |
Drive Frequency | 8kHz |
